Model Exchange Protocol

The Model Exchange Protocol enables your application to securely request and receive configured language models from FlowDown. Instead of asking users to copy-paste sensitive credentials, you can use the FlowDownModelExchange framework to handle the secure handshake and data transfer.

::: info Version Requirement This protocol requires FlowDown version 4.1.4 or later installed on the user's device. :::

Installation

Currently, FlowDownModelExchange is distributed as part of the FlowDown source tree and not hosted on a separate public repository. You need to integrate it manually.

1. Locate the directory Frameworks/FlowDownModelExchange in the FlowDown repository.
2. Copy the entire folder into your project workspace.
3. Add it as a Local Package in Xcode (File -> Add Package Dependencies -> Add Local...), or directly include the source files in your target.

Usage

1. Initialization

First, initialize a key pair. You should persist this key pair if you want to maintain the same identity across sessions, or generate a new one for each session.

import FlowDownModelExchange

// Generate a new key pair for encryption and signing
let keyPair = ModelExchangeKeyPair()

// Initialize the request builder
let builder = ModelExchangeRequestBuilder(
    callbackScheme: "my-app-scheme", // Your app's URL scheme
    keyPair: keyPair
)

2. Request Models

When you want to request models from FlowDown, use the builder to create a signed URL and open it.

func requestModels() {
    do {
        // Create a signed request URL
        let request = try builder.makeExchangeURL(
            session: UUID().uuidString,
            appName: "My Awesome App",
            reason: "To assist with coding tasks",
            capabilities: [.audio, .developerRole], // Filter needed models
            multipleSelection: false
        )

        // Open FlowDown
        UIApplication.shared.open(request.url)
    } catch {
        print("Failed to build request: \(error)")
    }
}

3. Handle Response

Configure your app to handle the callback URL (e.g., in onOpenURL or AppDelegate).

func handleCallback(url: URL) {
    guard let components = URLComponents(url: url, resolvingAgainstBaseURL: false),
          let queryItems = components.queryItems else { return }

    let params = Dictionary(uniqueKeysWithValues: queryItems.map { ($0.name, $0.value ?? "") })

    // Check the stage
    if params["stage"] == "completed" {
        handleCompletion(params: params)
    } else if params["stage"] == "cancelled" {
        print("User cancelled the operation")
    }
}

4. Decrypt Payload

Once you receive the completed callback, use the framework to decode and decrypt the payload.

func handleCompletion(params: [String: String]) {
    guard let payloadString = params["payload"],
          let sessionID = params["session"] else { return }

    do {
        // 1. Decode the encrypted payload wrapper
        let encryptedPayload = try ModelExchangeEncryptedPayload.decode(from: payloadString)

        // 2. Decrypt the data using your key pair
        let decryptedData = try ModelExchangeCrypto.decrypt(
            encryptedPayload,
            with: keyPair
        )

        // 3. Parse the model data (usually a Property List)
        let models = try PropertyListSerialization.propertyList(
            from: decryptedData,
            options: [],
            format: nil
        )

        print("Received models: \(models)")
    } catch {
        print("Decryption failed: \(error)")
    }
}

Security

The framework handles the security details for you:

• Signatures: Requests are signed with your private key to prevent tampering.
• Encryption: Data is encrypted using ChaChaPoly (Symmetric) and Curve25519 (Key Agreement).
• Forward Secrecy: Ephemeral keys are used for the exchange session.

Data Format

The decrypted data is a serialized Property List (Plist) containing:

• Model display names
• Endpoint URLs
• Authentication headers (including sensitive credentials)
• Model capabilities

Treat this data with the highest level of security. Do not log sensitive fields in production.
